Canton Atelier OnWall 9 C Center On-Wall Speaker, White (Each)

The Canton Atelier OnWall 9 C is a center on-wall speaker that houses the dialogue channel of a more compact home cinema visibly on the wall.

It's matched to the Atelier OnWall 9 front speakers and mounts horizontally via the same VESA bracket, usually directly under the TV. No wall cut-out, no dust.

Why the Atelier OnWall 9 C?

Because a good center speaker needs more than two drivers flanking the tweeter. A 128 mm aluminum-titanium midrange driver, a dedicated woofer and two passive radiators give voices substance without the horizontal layout buckling under the strain.

What you hear

Dialogue with body that doesn't float between the front speakers, but stays firmly anchored to the picture. The transition to the OnWall 9 front speakers stays seamless as the camera pans — even at the edge of the sofa.

Who is the Atelier OnWall 9 C suited for?

For mounted home cinemas of medium size, ideal with the Atelier OnWall 9 as front speakers. Plain talk: if you mainly listen to stereo, you don't need a center — that budget belongs in the fronts. And if you want a completely invisible wall, go for the InWall 9 C.

Our verdict

The logical partner to the OnWall 9 front speakers, surface-mounted instead of built in — and so the pragmatic answer for anyone who can't or doesn't want to cut a hole in the wall.

Technical data

• Type: Center on-wall speaker, 3-way bass reflex system with passive radiators, horizontal (passive)
• Drivers: 1× 25 mm aluminum tweeter, 1× 128 mm aluminum-titanium midrange driver, 1× woofer, 2× passive radiators
• Frequency response: 35–40,000 Hz
• Crossover frequency: 3,000 Hz
• Nominal impedance: 4–8 Ω
• Power handling (nominal/music): 120 / 180 W
• Sensitivity (2.83 V/1 m): 89.5 dB
• Mounting: wall bracket, VESA-compatible (100 × 100 mm), tiltable and swivelling
• External dimensions (W × H × D): 95 × 24.5 × 8.5 cm
• Weight: 8.2 kg
• Finish: white satin, frameless fabric cover
• Sales unit: 1 piece
• Included: center on-wall speaker with frameless fabric cover, wall bracket, feet

Frequently asked questions

How is the Atelier OnWall 9 C mounted?

Via a VESA-compatible bracket (100 × 100 mm), oriented horizontally, usually placed under the TV. A wall cut-out is entirely unnecessary. We work out the exact position based on your seating position and screen size.

Does the OnWall 9 C match the Atelier OnWall 9 front speakers?

Yes, both share the same drivers and frequency response, just mounted horizontally instead of vertically. That gives you a homogeneous front stage with no audible break during a pan. We're happy to check other combinations for you as well.

Why do I even need a dedicated center speaker?

The center reproduces dialogue and anchors it firmly to the picture. Without it, voices float between the front speakers as soon as you sit off to the side. This makes a noticeable difference, especially with quietly mixed series.

Is the Atelier OnWall 9 C delivered individually?

Yes, the sales unit is one piece. Order front speakers and subwoofer separately; we put together the complete parts list for your setup before you order.

Why buy the Canton Atelier OnWall 9 C from HD Zürisee?

Because a home cinema works as a system, not as a single component. We match center, fronts and amplifier to each other, and Mauri handles the installation on site if needed. Tell us about your room — we'll think it through with you.
