Canton Atelier OnWall 11 On-Wall Speaker, black (Piece)

The Canton Atelier OnWall 11 is an on-wall speaker that mounts the flat 3-way sound of the Atelier series visibly on the wall instead of building it in.

Where the InWall 11 disappears into the wall cavity, the OnWall 11 hangs directly in front of the wall on a slim VESA mount – no cutout, no construction mess, just two drill points. The front stays the same: frameless, satin-black fabric cover, with the same technology behind it as its big brother.

Why the Atelier OnWall 11?

Because you want the sound of the InWall 11 but can't or aren't allowed to cut into the wall – rented flat, concrete wall, or you're simply not yet sure about the position. Two 174 mm aluminium-titanium mid-woofers and two passive radiators pull 32 Hz of depth out of a cabinet that protrudes less than 10 cm from the wall. The 25 mm aluminium tweeter sits centrally and keeps voices exactly at ear height.

What you hear

Controlled bass instead of wall boom, clear mids, treble without harshness. As a stereo pair, the OnWall 11 builds a soundstage you'd hardly expect from its flat look; as left and right front channels, it completes a home cinema setup without anyone noticing exactly where the speaker is hanging.

Who is the Atelier OnWall 11 for?

For anyone who wants the look of a built-in speaker but can't or isn't allowed to build one in: rented properties, concrete walls without lead time, rooms where a move isn't out of the question. Plain talk: anyone already open to a wall cutout gets the same look, just a touch more discreet, with the InWall 11. And the OnWall 11 isn't made for bathrooms or outdoor use either.

Our verdict

The compromise that doesn't sound like one. Anyone who wants serious sound on the wall but has neither the tradesperson nor the nerves for a wall cutout gets almost the full InWall experience here – just mounted on top instead of set into the wall.

Technical data

• Type: on-wall speaker, 3-way bass reflex system with passive radiators (passive)
• Drivers: 1× 25 mm aluminium tweeter, 2× 174 mm aluminium-titanium mid-woofers, 2× passive radiators
• Frequency response: 32–40,000 Hz
• Crossover frequency: 3,000 Hz
• Nominal impedance: 4–8 Ω
• Power handling (nominal/music): 140 / 200 W
• Sensitivity (2.83 V/1 m): 89.5 dB
• Mounting type: wall bracket, VESA-compatible (100 × 100 mm), tiltable and swivelling
• Outer dimensions (W × H × D): 32.5 × 115 × 9.5 cm
• Weight: 13 kg
• Finish: black satin, frameless fabric cover
• Sales unit: 1 piece
• Included: on-wall speaker with frameless fabric cover, wall bracket, device feet

Frequently asked questions

How is the Atelier OnWall 11 mounted – do I need a wall cutout?

No. The OnWall 11 is mounted directly in front of the wall via a VESA-compatible bracket (100 × 100 mm), so you need no cutout and no access to the wall cavity. Two solid drill points are enough; we work out the exact position and cable routing with you beforehand.

What's the difference to the Atelier InWall 11?

Both share the same drivers, sound and format – the InWall 11 disappears flush into the wall, the OnWall 11 hangs visibly in front of it. For rented flats, concrete walls, or uncertain future plans, the OnWall 11 is the less complicated choice. We'll tell you honestly which variant suits your wall.

Is the OnWall 11 suited for stereo or home cinema?

Both. As a pair, it plays full-fledged stereo; as left and right front channels, it forms the basis of a home cinema setup. For dialogue, you add the matching Atelier OnWall 11 C centre channel. We put together the right combination for your room in advance.

Is the Atelier OnWall 11 sold individually or in pairs?

Individually – Canton offers it as a single speaker, so our sales unit is accordingly one piece. For stereo or a left and right front you need two pieces, and for home cinema the centre channel is added. We're happy to work out the parts list with you beforehand.

Why buy the Canton Atelier OnWall 11 from HD Zürisee?

Because even a surface-mounted wall installation lives or dies by planning: height, cable routing, matching electronics. HD Zürisee in Wädenswil brings years of practical experience to this, and sends Mauri for mounting and wiring if needed. Call us or drop us a line.
